Deliver high-quality and reliable solution that saves energy and money
Output Current Selectable

Output Current Selectable

Less inventory! Thanks to the selectable output current using the DIP switches

Superior Lighting Performance

Superior Lighting Performance

Deliver smooth dimming visual experience and have the precise control of power to produce accurate color tuning

Flicker-Safe Dimming

Flicker-Safe Dimming

The constant current LED drivers deliver smooth and flicker-safe dimming

Additional features

Additional features

  • High efficiency >85% and low THD <15%
  • Power factor greater than 0.95
  • For luminaires of protection class I (input), class Ⅱ (output)
  • Overload, short circuit, no load and surge protection
  • Over-the-Air (OTA) firmware updates
Book a Demo

Book a Demo

Get to know Ldrive 36W in detail by talking to our lighting experts. Get a personalized demo session to get all your queries answered.

Book a demo

I want more details

Connectivity: Bluetooth

Rated Supply Voltage: 120-277VAC

Max Supply Voltage: 108-305VAC

Max Input Current: 0.35A

Max Output Power: 33.2W

Efficiency: 85%

Power Factor: 0.95

Output Current: 450-800mA

Output Current Tolerance: ±7.5%

Max Case Temperature: 80°C, 176°F

Storage Temperature: -20 to 80°C (-4°F to 176°F)

Dimensions: 12.76 x 1.19 x 0.82 in (324 x 30 x 21 mm)

Ldrive 36W
